Passive CCTV Rj45 Balun HD-CVI/TVI/AHD Press Fit Video Baluns with Pigtail for CAT5 CAT6(VB102PH-3)
Product Overview
Product Description
Passive CCTV Rj45 Balun HD-CVI/TVI/AHD Press Fit Video Baluns with Pigtail for CAT5 CAT6(VB102PH-3)
Features
Compatible with all HD-CVI, HD-TVI, HD-AHD Cameras and analog Cameras
Transmission Distance
|
CVBS
|
Color video max up to 400m
|
|
HD-AHD
|
720P: Color video max up to 300m
|
|
1080P:Color video max up to 200m
|
|
3MP,4MP,5MP: Color video max up to 170m
|
|
HD-TVI
|
720P: Color video max up to 300m
|
|
1080P:Color video max up to 200m
|
|
3MP,4MP,5MP: Color video max up to 170m
|
|
HD-CVI
|
720P: Color video max up to 300m
|
|
1080P:Color video max up to 200m
|
|
3MP,4MP,5MP: Color video max up to 170m
|
No power required
60dB cross talk and noise immunity
Compact size and easy installation
Built-in transient suppression protection
Technical Specifications
| Model |
VB100WH |
VB103P |
VB106
VB106PH |
VB202EH
VB202PH
VB202PEH |
VB105EH
VB105PH
VB105PEH
VB107E
VB107P
VB107PR
|
VB102EH
VB102PH
VB102PEH
VB103EH
VB103PH
VB103PEH
|
VB203EH
VB203PH
VB203PEH
VB107EH
VB107PH
VB107PRH
VB109EH
VB109PH
|
VB303T&R
VB303T&R(P)
VB303T&RH(P) |
| UTP Connection |
Wire |
RJ45 |
Quick Connector |
Screw Terminal Blocks |
"Press-Fit" Terminal Blocks
|
| Built-in Video Ground Loop Isolator |
× |
× |
× |
× |
× |
× |
× |
√ |
| Innovative connectable design |
× |
× |
× |
× |
√ |
× |
√ |
√ |
| Video Format |
HD-CVI/TVI/AHD, CVBS |
| Frequency Response |
DC to 60MHz |
| Attenuation |
0.5dB typ |
| CMRR |
60 dB |
| Surge Protection |
4KV |
| ESD |
8KV |
| Impedance |
Coax, Male BNC |
75 ohms |
| Terminal Block |
100 ohms |
| Working Environment |
Working Temperature |
-10℃ to +50℃ |
| Storage Temperature |
-30℃ to +70℃ |
| Humidity |
0 to 95% |
Transmission
Distance |
720P CVI/TVI/AHD Cameras |
Up to 300m |
| 1080P CVI/TVI/AHD Cameras |
Up to 200m |
| 3MP, 4MP, 5MP CVI/TVI/AHD Cameras |
Up to 170m |
| Wire Type |
CAT5, CAT5E, CAT6 |
| Power |
No power required |
| Case |
ABS Plastic |
